◆   Integrative structure. Low deflection,low oscillating,high stability.

  ◆   high-strength stainless steel drive system and high precision aluminum alloy SYN gear

  ◆   Load weight up to 50KG, available for containg ultra long focal-length zoom lens

  ◆   Auto angle-calibrate function

  ◆   All-weather design, adapted to  -40℃～+60℃

  ◆   High-strength aluminum-alloy housing, anti-impact, anti-corrosion,IP66. With wiper and demist function.

  ◆   Pan:360°,Non-Limited Position, Tilt 120°(-60°～+60°)

  ◆   Built-in OSD Menu,support changing information and parameter of the dome, support setting and calling Presets, tour, scan, pattern, camera mode, display name and etc.

  ◆   Up to 128 presets(titles can be set), support tour and preset running time and speed reserve.

  ◆   8 programmable zones with titles, 4 PATTERN, Each recording time is not less then 180s

  ◆   4 Scan,support scan between left and right limited at an appointed speed.

  ◆   Park action function, support auto-calling presets or start-up tour, pattern and scan after dome idle for a period of time

  ◆   Real time function, support pre-seting dome action at an appointed time in any day or month via OSD menu

  ◆   Built-in memorizer can store parameters of camera & functions of PTZ.

  ◆   Temperature display function, can survey the temperature inside of dome.

  ◆   PT postions nad Zoom display

  ◆   Alarm fucntion, 7 in and 2 out

  ◆   Privacy masking, to shield the private region from displaying on the screen.

  ◆   Power-up function, available for pre-setting the PTZ reboot action via OSD menu

  ◆   Communication: RS485/RS422 ,Manchester,BI-PHASE

  ◆   Built-in multi-protocols and fully compatible with PELCO-D、PELCO-P、KALATEL, VICON, BOSCH(PHILIPS), SENSORNT, AD, VIDO B02, etc.

  ◆   IP66 all-weather protect, built-in constant temperature device

  ◆   lightning-proof: Video,communication and power input port all have 2-3 grade protective circuits

  ◆   Built-in TVS4000V lightning-proof, surge-proof and wave-proof.
